The Sinister-SDX 2500 Class D Mono Block Subwoofer Amplifier is the most powerful amplifier Wet Sounds has ever built. Employing Class D technology plus the Wet Sounds exclusive MAXED Power Supply, the Sinister-SDX 2500 achieves an efficiency rating of over 87% - one of the highest available in a marine amplifier. This means more power, less current drain, less strain on the electrical system, less generated heat. All resulting in more playing time!
The Sinister-SDX 2500 uses the same intelligent microprocessor controlled protection circuitry used on all Sinister SDX amplifiers for overvoltage/undervoltage protection, DC offset & speaker short protection, as well as thermal rollback to ensure consistent play in the harsh marine environment. The protection circuitry is displayed in the back lit Wet Sounds shield logo. Please refer to the user’s manual for details about the protection circuitry.
As further protection against use in the harsh marine environment, the SDX2500 includes a sealed chassis for the top mounted controls, and a four-layer conformal coated PC Board.
Features:
• Master/Slave configuration – Allows control of 2 or more SDX2500s from 1 set of controls. Gains, crossovers, bass boosts, subsonic filters, and remote levels can be controlled from a single “Master” SDX2500 amplifier. This eliminates gain/crossover matching normally needed when using multiple amplifiers. Also eliminates the use of RCA “Y” adaptors.See the user’s manual for more detail on this feature.
• Remote Level Control – Included in all Sinister SDX amplifiers allows control of the total output of the amplifier.The Remote Level Control will never exceed the gain level set on the chassis of the amplifier. This control should be used as a convenience when only the bass output in the system needs to be decreased.
• Multi color top mounted LED Badge – All Sinister amplifiers come equipped with the Wet Sounds shield logo badge that can be set to display Red, White or Blue as the status indicator. The badge can also be rotated for vertical or horizontal placement – depending on how the amplifier is mounted.
- Mono @ 4 Ohms:
- 1000W x 1 @ < 1% THD
- Mono @ 2 Ohms:
- 1700W x 1 @ < 1% THD
- Mono @ 1 Ohm:
- 2500W x1 @ < 1% THD
- Input Sensitivity:
- 0.2V – 6.0V
- Crossover Range Low Pass:
- 50Hz – 150Hz 12dB/Octave
- Crossover Range Subsonic Filter:
- 10Hz – 50Hz 12dB/Octave
- Output Power (RMS):
- @ 1% 100Hz 14.4V CEA 2006
- Bass Boost:
- 0 - 12dB Variable 30Hz – 125Hz
- Fusing:
- 6 x 40A ATC fuses
- Power Ground Input:
- 1/0 AWG wire capable
- Channels:
- Monoblock
- Dimensions:
- 22.125” (L) x 10.25” (W) x 3.0” (H)
- Frequency Response:
- 10Hz – 150 Hz
- Class D:
- True
- Series:
- Sinister
This warranty does not cover fading or discoloration caused by exposure to sunlight or chemicals such as ammonia, household bleach, or any cleaning material that contains abrasive substances. (For information on how to prevent fading or discoloration, consult for recommendations on cleaning products) Wet Sounds, Inc. does not cover the cost for removal and reinstallation of any kind. Additionally, shipping TO Wet Sounds, Inc. is covered by the purchaser This warranty is void and inapplicable if Wet Sounds deems that the product was abused or misused; including but not limited to Speaker product that has been improperly-powered (under or over powered), causing thermal (burnt voice coil) and/or mechanical failure (torn surrounds or spiders), damage caused by accident, mishandling, improper installation, negligence, normal wear and tear, excessive water or heat damage, freight damage or products that have been altered in any way. Product owned by anyone other than the original purchaser from an authorized Wet Sounds dealer. (The warranty is not transferable and will not apply to products purchased from unauthorized dealers.) Wet Sounds is not responsible for any damages to a consumer's boat or person from a product failure. The warranty is void if Wet Sounds deems the product was installed or used improperly. Wet Sounds shall not be responsible for any incidental or consequential damages, except to the extent provided (or prohibited) by applicable law. This warranty gives you specific legal rights, and you may also have other rights which vary from state.
What Wet Sounds, Inc. Will Do
Wet Sounds, Inc will repair any part of your product that proves to be defective in materials or workmanship. In the event repair is not possible, Wet Sounds, Inc will replace the product in question. If it is deemed necessary Wet Sounds, Inc. will either replace the entire product with a refurbished unit or it will be replaced with a model that is similar in price if that model is no longer available. Labor cost and materials needed to complete this service will be at no charge to the purchaser. Additionally, the cost of shipping TO the consumer is also covered under this warranty.
How to Obtain Warranty Service
Contact Wet Sounds, Inc. either by phone at 877-938-7757 or by email at WARRANTY@WETSOUNDS.COM. A service representative will assist you in the necessary actions to verify that the problem that you are experiencing is covered under warranty. If it is in fact a warranty issue, Wet Sounds will issue an RA number for tracking purposes and give instructions on sending the product in for evaluation. Wet Sounds, Inc. How State Law Applies This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Internet Warning
Wet Sounds, Inc. products sold on any non authorized web site or internet auction site are void of any and all manufacturer's warranty. Please contact Wet Sounds at 877-938-7757 or visit our web site at WWW.WETSOUNDS.COM to search for an authorized site and/or an authorized retailer near you.
