Free Air REVO subs are recommended primarily for Infinite Baffle (Free Air) applications where a dedicated subwoofer enclosure is not available or practical.
Both 10” & 12” REVO FA subs are available in White or Black frames (Black frames use metallic grey cones). All REVO FA Subs are available in either single 2 Ohm or single 4 Ohm impedances.
All REVO 10” & 12” Subwoofers share the same design features:
• Nylas Composite Frame - to withstand extreme environmental use. Designed to accept optional RGB wiring.
• Injection Molded Composite Cone – For durability & low distortion.
• Santoprene Rubber Spider – Much more durable to water & temperature changes than a traditional treated Cotton Spider used by the majority of marine speakers & subwoofers.
• Santoprene Rubber Surround – Offers a superior bond to the composite cone.Also resists deterioration due to water, temperature & ultraviolet exposure.
• Stainless Steel Terminals – Designed to resist corrosion.
All REVO Subwoofers are sold without grills. 8 different grill designs are available separately for all versions of 8", 10” & 12” REVO HP & FA subwoofers.This will enable users to have matching grills on both REVO Coaxial In-Boat speakers & REVO Subwoofers.
Optional RGB LED Kits are available to fit under all REVO 8", 10” & 12” subwoofer grills to enable users to have thousands of LED light display combinations.
- Mounting Depth:
- 4.62 inches w/grill (117.47 mm)
- Frequency Response:
- 20Hz to 500HZ
- Sensitivity:
- 88 db at 1watt/1 meter
- Diameter:
- 11.02 inches w/grill (279.90 mm)
- Weight:
- 10 lbs (4.53 kg)
- RMS Watts:
- 300
- PEAK Watts:
- 600
- Impedance:
- 2ohm
- Hole Cut Out:
- 9.45 inches (240.03 mm)
- Box Specs:
- Optimized for Infinite Baffle (Free Air) applications or 1.3 cu ft sealed enclosure
- Sub Size:
- 10"
- Series:
- REVO
- Cone Color:
- Black
- Application Type:
- Free Air
